วิธีแก้ปัญหาติดตั้ง UEFI Windows บนดิสก์แบบ MBR ไม่ได้ | เรียนรู้การเขียนโปรแกรมออนไลน์ ที่เว็บไซต์

คุณกำลังพยายามหาข้อมูลเกี่ยวกับหัวข้อการหาเงินออนไลน์หรือไม่? คุณกำลังมองหาหัวข้อที่เหมาะสม วิธีแก้ปัญหาติดตั้ง UEFI Windows บนดิสก์แบบ MBR ไม่ได้ หรือไม่? ถ้าเป็นเช่นนั้นโปรดอ่านบทความนี้ทันที.

ดูวิดีโอโดยละเอียดด้านล่าง

วิธีแก้ปัญหาติดตั้ง UEFI Windows บนดิสก์แบบ MBR ไม่ได้


เมื่อคุณต้องการติดตั้ง Windows ใหม่โดยบูตแบบ UEFI แต่ไม่สามารถเลือกดิสก์ที่ต้องการได้ และเมื่อดูที่รายละเอียด จะมีข้อความแจ้งเตือนว่า
Windows cannot be installed to this disk. The selected disk has MBR partition table. On EFI system, Windows can only be installed to GPT disks.
แสดงว่าดิสก์ที่คุณเลือกนั้นมีพาร์ทิชั่นเป็น MBR ซึ่งไม่สามารถติดตั้ง Windows ที่บูตแบบ UEFI ได้

คำเตือน: วิธีด้านล่างนี้ จะแปลงรูปแบบดิสก์ ซึ่งจะเป็นการล้างข้อมูลบนดิสก์ออกทั้งหมด ถ้าคุณมีข้อมูลสำคัญบนดิสก์ คุณต้องสำรองหรือย้ายข้อมูลไปไว้ที่อื่นก่อน

วิธีการแก้ไขในวิดีโอนี้ จะใช้วิธีการแปลงรูปแบบดิสก์จาก MBR ให้เป็น GPT บนดิสก์ที่ต้องการติดตั้ง Windows ซึ่งมี 2 วิธีดังนี้
1. การลบพาร์ทิชั่นออกให้หมดและให้ Windows แปลงเป็น GPT ให้เอง
1.1 เลือกพาร์ทิชั่นที่ต้องการลบ และกด Delete
1.2 ถ้ายังมีพาร์ทิชั่นอื่นบนดิสก์นี้อีก ก็ให้ทำเช่นเดียวกับ 1.1
1.3 เมื่อสถานะที่ดิสก์เป็น Unallocated space แล้ว คุณสามารถเลือกที่จะติดตั้งระบบบนดิสก์นี้ได้เลยโดย Windows จะฟอร์แมตเป็น GPT ให้เอง
2. การแปลงดิสก์เป็น GPT ด้วยคำสั่ง diskpart
2.1 กด Shift + F10 เพื่อเปิดหน้าต่าง command prompt
2.2 พิมพ์คำสั่ง diskpart และกด Enter
2.3 พิมพ์คำสั่ง list disk และกด Enter เพื่อแสดงดิสก์ทั้งหมดบนเครื่องนี้
2.4 เลือกดิสก์ที่ต้องการ และพิมพ์ select disk ตามด้วยตัวเลขของดิสก์ เช่น select disk 0 และกด Enter
2.5 พิมพ์คำสั่ง clean และกด Enter เพื่อล้างข้อมูลบนดิสก์นี้
2.6 พิมพ์คำสั่ง convert gpt และกด Enter เพื่อแปลงดิสก์นี้ให้เป็น GPT
2.7 พิมพ์ exit เพื่อออกจากโปรแกรม และปิดหน้าต่าง command prompt นี้
2.8 กดปุ่ม Refresh เพื่ออัพเดตสถานะของดิสก์
2.9 ตอนนี้ คุณสามารถเลือกดิสก์นี้เพื่อติดตั้ง Windows แบบ UEFI ได้แล้ว

อีกวิธีหนึ่ง ถ้าคุณไม่ต้องการแปลงดิสก์เป็น GPT คุณสามารถเลือกที่จะบูตแบบ legacy BIOScompatibility แทน UEFI ได้ แต่ผมจะไม่ลงรายละเอียดในวิดีโอนี้

แหล่งข้อมูลอ้างอิง
Windows Setup: Installing using the MBR or GPT partition style
https://technet.microsoft.com/enus/library/dn336946.aspx

วิธีแก้ปัญหาติดตั้ง UEFI Windows บนดิสก์แบบ MBR ไม่ได้

Windows cannot be installed to this disk. the selected disk has an MBR partition table


Windows cannot be installed to this disk. the selected disk has an MBR partition table. On EFI systems, windows can only be installed to GPT disks MBR can’t support partitions which are larger than 2 TB.

So we need to convert to GPT

Shift + f10
type: Diskpart
type: List Disk
type: Select Disk (and whatever number disk you want to change)
type: Clean
type: Convert GPT

get all your computer problems solved at
http://www.briteccomputers.co.uk

Windows cannot be installed to this disk. the selected disk has an MBR partition table

MBR and GPT Partition Tables


The partition table on a drive determines the structure of the data and this video will look at the MBR and GPT partition tables. Check out http://YouTube.com/ITFreeTraining or http://itfreetraining.com for more of our always free training videos. In some cases the operating system will choose the partition table for you, however having an understanding of the partition tables will help you understand what features each has as well as any compatibility problems that may occur due to the choice of partition table.

Download the PDF handout http://ITFreeTraining.com/handouts/se…

Partition Tables
Before data can be stored on a device like a hard disk, a partition table needs to be created. This partition table defines where the data can be stored on the device. For example, if you had a 3 terabyte hard disk, you could create 2 partition tables. One partition could be 1 terabyte in size while the other could be 2 Terabytes in size. The partition table essentially determines which part of the hard disk can be used for what.

There are two different partition types available. These are MBR (Master Boot Record) and GPT (GUID Partition Table). MBR is the older style that offers more compatibility while GPT is newer and offers more features, most notably, it supports larger devices. In some cases, GPT may require particular hardware in order to run.

See also  เกม Live Service ที่ดีควรมีองค์ประกอบอะไรบ้าง | Online Station Podcast #1 | เรียนรู้การเขียนโปรแกรมออนไลน์ ง่ายที่สุดโดย Marketingtangtruong.com

Master Boot Record (MBR)
MBR has been around since the first PC’s were released. For this reason it should work on all computers, meaning it has great compatibility with existing hardware. MBR is limited to 4 primary partitions. To increase the number of partitions that could be created on a single drive, one of the MBR partitions could be converted into an extended partition. This extended partition contains configuration allowing additional partitions to be created. In DOS days, there could only be 26 partitions on one hard disk: 3 primary partitions and one extended partition that contained 23 additional partitions. This was a limitation due to each drive requiring a drive letter and thus a limit of 26 letters in the alphabet. In later operating systems more than 26 partitions could be created using extended partitions. The biggest limitation of MBR is that it can only use 2 Terabytes of space. If you have a drive bigger than 2 Terabytes, MBR can be used, but any space after 2 Terabytes will not be useable and thus will be wasted.

GUID Partition Table (GPT)
The GPT partition table supports 128 primary partitions and thus does not require any extended partitions. The main advantage of the partition table is it supports drives in the Zettabyte size. 1 ZB = 1 000 000 000 000 000 000 000 bytes or 10 to power of 21 bytes or 1 billion terabytes. In order to boot an operating system for a GPT partition, you require a hard disk that supports “Unified Extensible Firmware Interface” or UEFI. This was designed to be a replacement for the older system called “Basic Input/Output System” or BIOS. The operating system also needs to support booting. For Windows this means Windows XP and Windows 2003 64 bit editions or above. For Linux most distributions should support both 32bit and 64bit operating systems. It is matter of checking the distribution to ensure it does. All modern Linux distributions should support this. If the hardware or operating system does not support booting, it is possible that the operating system will still be able to read the drive as a data drive. Every Windows operating system including and after Windows Vista and Windows Server 2003 SP1 will support GPT as a data drive.

Converting between the two
If your hard disk is less than 2 terabytes, use MBR. This will offer you the most compatibility. If you do need to change between the two, most likely GPT to MBR, Windows can convert the drive; however, it will first need to have all the partitions removed thus erasing all the data on the drive. Thirdparty software is available for Windows which can convert the partition table without losing the data. Otherwise there is Linux software which can perform the conversion. Before converting the partition table, make sure that you back up all data on the drive.

See http://YouTube.com/ITFreeTraining or http://itfreetraining.com for our always free training videos. This is only one video from the many free courses available on YouTube.

References
“Installing and Configuring Windows Server 2012 Exam Ref 70410” pg 42 43
“GUID Partition Table” http://en.wikipedia.org/wiki/GUID_Par…
“http://en.wikipedia.org/wiki/Partitio…” http://en.wikipedia.org/wiki/Partitio…
“Extended boot record” http://en.wikipedia.org/wiki/Extended…

MBR and GPT Partition Tables

MBR and GPT Partition Tables


Welcome to the ITFreeTraining video on MBR and GPT partition tables. A partition table forms the low level data structure of a drive. Check out http://itfreetraining.com for more of our always free training videos. By the end of this video, you will understand what partition tables are available and what features each offer.

Access the rest of the course http://ITFreeTraining.com/server
Download the PDF handout http://ITFreeTraining.com/handouts/server/mbrgpt.pdf

Partition Tables
0:20 – Before a drive can be used by an operating system, whether it be physical or virtual, a partition table needs to be created on the drive. The partition table forms the low level data structure of the drive. This structure allows the drive to be divided up into individual partitions. If I were to have a physical drive that has a partition table created on it, the drive will contain only unused space. Before the unused space can be used, the drive needs to be divided up into one or more partitions. In this case, the drive will be divided up into 3 partitions. In many cases, it is common for a hard drive to be divided up into one large, main partition for the operating system and its data, and some smaller partitions for booting, recovery, and tools. After creation, a partition table can be formatted for the operating system to store data on. There are two partition tables that are available. These are MBR and GPT. MBR is older and this has more compatibility with older and obsolete operating systems and hardware. GPT is a newer standard and has more features but requires newer operating systems and, depending on what you are trying to achieve with it, it may also require newer hardware. To start with, I will look at MBR.

See also  EP212 คลินิกเกษตร มะพร้าวเป็นอะไร ทำไมใบเหลือง | เรียนรู้การเขียนโปรแกรมออนไลน์ ที่เว็บไซต์ Marketingtangtruong.com

Master Boot Record (MBR)
1:38 – The MBR or Master Boot Record, was first introduced on PC’s back in 1983. Since then it has become the de facto standard for PC’s working on DOS based, Windows based, and alternative operating systems like Linux. If the MBR partition table is used, this allows the drive to be divided up into a maximum for 4 primary partitions. The operating system allows each partition to be formatted to use a file system. So with MBR, the administrator could create 4 primary partitions and format them so the operating system can see 4 drives. In most cases, this should be sufficient for most requirements. However, in some rare cases it may be necessary for more than 4 partitions. If this is the case, one of the primary partitions can be changed into an extended partition. In the DOS days, this extended partition could hold 23 partitions. This was a limitation of DOS since it could only support 26 drive letters. On modern Windows operating systems, the administrators can create as many extended partitions as they wish. However, extended partitions are linked to each other so if you use a lot of them they could have an impact on performance. Also, the BIOS in the computer may not support booting from an extended partition; however, a workaround would be to place the boot loader on a primary partition that would boot the operating system stored in the extended partition. The MBR partition table offers the fundamental features required for an operating system and offers compatibility with older operating systems and hardware. The only limitation is that it is limited to 2 Terabytes of usable space. If the administrator uses MBR on a drive larger than 2 Terabytes, all the space after Terabytes will be unavailable to the operating system and thus unusable. There is some new technology that has been developed to extend the life of MBR which I will look at later on in this video. Before this, I will have a look at MBR’s replacement, GPT.

See http://itfreetraining.com/server/mbrgpt for the rest of this description along with our always free training videos. This is only one video from the many free courses available on YouTube.

References:
“Installing and Configuring Windows Server 2012 Exam Ref 70410” pg 42 43
“GUID Partition Table” http://en.wikipedia.org/wiki/GUID_Partition_Table
“Partition table” http://en.wikipedia.org/wiki/Partition_table
“Extended boot record” http://en.wikipedia.org/wiki/Extended_boot_record
“Windows support for hard disks that are larger than 2 TB” http://support.microsoft.com/kb/2581408
“GUID Partition Table” http://en.wikipedia.org/wiki/GUID_Partition_Table
“Advanced Format” http://en.wikipedia.org/wiki/Advanced_Format
“Windows and GPT FAQ” https://msdn.microsoft.com/enus/library/windows/hardware/dn640535(v=vs.85).aspxgpt_faq_how_many_partitions

See also  โฟโต้ชอป photoshop CS6 - #55 สอนวิธีและเทคนิคการสร้าง gif frame animation | คู่มือการเขียนโปรแกรม ที่เว็บไซต์ Marketingtangtruong.com

Credits
Script: Phil Guld http://philguld.com
Voice Talent: HP Lewis http://hplewis.com
Companion Document: Phil Guld http://philguld.com
Video Production: Kevin Luttman http://www.KevinLuttman.com
Quality Assurance and Web Hosting: Edward M http://digitalmaru.com

MBR and GPT Partition Tables

HOW TO CONVERT A DRIVE FROM MBR TO GPT


In this video I’ll show you how to convert your hard drive (or SSD) from a MBR partition, to the more modern GPT. With this method YOU WILL LOSE ALL DATA ON THE DRIVE SO BACKUP FIRST!

I am using Windows 10, but the process is the same for Windows 7/8.
You can use the same process to go from GPT to MBR.

👉What’s the difference between MBR and GPT?
https://www.howtogeek.com/193669/whatsthedifferencebetweengptandmbrwhenpartitioningadrive/

👉SUBSCRIBE AND LIKE👍 IT’S FREE😎

🌟Directly support this content and channel🌟

Ethereum:
0x82111e3B4c433CAd4Cd71500725368b489f0b423

Bitcoin:
17ZDtMBXopFK4tpwG3iXU9WFznG65CgCJD

Bitcoin Cash:
127HvctzcxvGwP8LAamG7K8XSqPV4JzU2G

Litecoin:
LMdsQxvwo72aboVB2fA5kiq9YwyFNkvMKY

HOW TO CONVERT A DRIVE FROM MBR TO GPT

Do not under dos ghost non mbr partition! continue? 2020 | Songkhangluu✅


👉👉👉https://bit.ly/39rVANJ
Join now to enjoy the perks: https://www.youtube.com/channel/UCOXNdrf4JSHI3_q7ULv2Lg/join

Do not under dos ghost non mbr partition! continue? 2020 | Songkhangluu✅

Как перевести диск из mbr (MASTER BOOT RECOVERY) в gpt (GUID PARTITION TABLE) без потери данных!


Сегодня я розкажу как перевести диск mbr в gpt и gpt в mbr!
Ссылки:Mini Tool Partition: https://www.partitionwizard.com/freepartitionmanager.html
Телеграмм канал: https://t.me/Tymalayker

Как перевести диск из mbr (MASTER BOOT RECOVERY) в gpt (GUID PARTITION TABLE) без потери данных!

THE SELECTED DISK HAS AN MBR PARTITION TABLE window không cài được vào ổ đĩa phân vùng MBR


“Windows cannot be installed to this disk. The selected disk has an MBR partition table. On EFI systems, windows can only be installed to GPT disk”
“Windows không thể được cài đặt vào đĩa này. Đĩa đã chọn có một bảng phân vùng MBR. Trên các hệ thống EFI, cửa sổ chỉ có thể được cài đặt vào đĩa GPT ”
Video hướng dẫn 2 cách khắc phục lỗi MBR này bằng cách convert phân vùng MBR sang GPT bằng usb boot ISO window và định dạng lại ổ cứng bằng lệnh trên cửa sổ CMD.
BẠN THAM KHẢO THÊM 1 SỐ VIDEO KHÁC:
Học làm video với Camtasia 9: https://www.youtube.com/playlist?list=PLAdb5r6ahTEt41EhB5WiVLU06Cn6uiuV
MIC THU ÂM: https://www.youtube.com/watch?v=aupyCiESd6A&list=PLAdb5r6ahTEu7o90KPYsAxGaNgB98oCcW&index=4
CÁCH TẠO BLOGGER: https://www.youtube.com/playlist?list=PLAdb5r6ahTEsUe2sL_z1aIFLryF9hXZM
Bạn vui lòng chia sẻ cho bạn bè và đăng ký kênh để theo dõi những video mới nhất được cập nhật thường xuyên bởi Gatiki. Cảm ơn Bạn rất nhiều!

Like kênh: http://bit.ly/2r5ekxv
Facebook: http://bit.ly/2rYDLzZ
Google+: http://bit.ly/2r5fcT3
Twitter: https://twitter.com/GATIKIONLINE
Website: http://www.gatiki.com

THE SELECTED DISK HAS AN MBR PARTITION TABLE window không cài được vào ổ đĩa phân vùng MBR

How To Convert MBR To GPT For Free In Windows 10


So you want to upgrade to Windows 11 but your partition table is set to MBR and you need to convert partition table to GPT without losing any data on the computer? well it can be done for FREE using MBR2GPT.exe which is built into Windows 10. I will show you step by step guide on converting MBR master boot record to GPT GUID Partition Table. We will being doing this in command prompt.

mbr2gpt /validate /disk:0 /allowFullOS

mbr2gpt /convert /disk:0 /allowFullOS

https://docs.microsoft.com/enus/windows/deployment/mbrtogpt

📃Watch related playlists and videos
✅https://www.youtube.com/user/Britec09/playlists

🚩 Connect with me on social:
✅ Follow on Twitter http://twitter.com/Britec09
✅ Follow on Facebook: http://facebook.com/BritecComputers

🎬 View my Website: http://BritecComputers.co.uk

💻Discord Access: https://discord.gg/YAuGm5j

🛍 Support me with your Amazon purchases:
UK https://amzn.to/3diZslY
US https://amzn.to/2OwZWux

💯Merch https://teespring.com/enGB/stores/britecstore

How To Convert MBR To GPT For Free In Windows 10

How to solve "windows cannot be installed … disk has an MBR partition" (Intel NUC M.2 SSD)


How to solve the Windows cannot be installed to this disk. The selected disk has an MBR partition table. On EFI systems, Windows can only be installled to GPT disks.

How to solve "windows cannot be installed ... disk has an MBR partition" (Intel NUC M.2 SSD)
